The semiconductor equipment bonding machine uses silicone rolls, shock-absorbing silicone rubber, and high-temperature silicone gaskets.

1. Core performance highlights

Ultra wide temperature resistance range: Long term temperature resistance of -60 ℃ to 260 ℃, short-term ability to withstand high temperatures of 300 ℃, no softening or release of harmful substances in high temperature environments, no brittle cracking or shrinkage in low temperature environments, able to stably adapt to high and low temperature alternating working conditions such as ovens, ovens, and high temperature pipelines, with a service life of over 8000 hours.

Strong mechanical and elastic properties: tensile strength ≥ 5MPa, elongation ≥ 150%, tear and wear resistance, able to resist damage caused by equipment vibration or friction; The compression permanent deformation rate is ≤ 12% (180 ℃× 72h), with long-lasting elasticity and the ability to tightly adhere to irregular surfaces, ensuring that the sealing or shock absorption effect does not weaken.

Excellent weather and corrosion resistance: UV resistance, ozone resistance, acid and alkali resistance (such as weak acid and alkali solutions, oil stains), not easily aged or discolored in outdoor exposure or chemical environments, with a performance degradation rate of less than 5% per year, suitable for complex environments such as outdoor equipment protection and chemical scene sealing.

Insulation and safety: Volume resistivity ≥ 10 ¹⁴Ω· cm, excellent insulation performance, can be used as insulation pads for electrical equipment; Using environmentally friendly silicone raw materials, compliant with RoHS standards, free of heavy metals and toxic additives, some models have passed FDA certification, and can be used in food or medical auxiliary scenarios.

2. Form and customization attributes

Conventional specifications: Width 0.5-2.2m (suitable for different equipment workbenches or production line widths), thickness 0.2-5mm (ultra-thin or thickened options can be selected as needed), length can be customized as needed (10-100m/roll), high flatness of the coil, thickness tolerance ≤± 0.05mm, convenient for continuous cutting, molding or stamping processing

Surface and color customization: supports two surface treatments: smooth (easy to clean, non adhesive) and matte (excellent anti slip performance, friction coefficient ≥ 0.7); The default colors are white and transparent, and can be customized with identification colors such as red and blue to meet scene differentiation or visual needs.

Function expansion customization: Additional additives such as flame retardant, conductive, and thermal conductivity can be added to make "high-temperature resistant flame retardant silicone coil" and "high-temperature resistant conductive adhesive coil", suitable for fields with special functional requirements such as electronics and new energy.

3. Applicable scenarios

Industrial sealing and insulation: used for door seals, pipeline interface gaskets, and insulation pads in high-temperature equipment (such as ovens, vulcanizers) to block heat transfer;

In the field of electronics and electrical engineering, as insulation protective film for circuit boards, heat dissipation pads for LED lamps, and buffer pads around batteries, it balances temperature resistance and insulation;

In the field of food and home furnishings, we produce high-temperature resistant baking rolls and food grade conveyor belt liners (requiring FDA certification) that are temperature resistant, safe, and non-toxic;

Automobile and Rail Transit: Suitable for engine peripheral sealing, vehicle mounted equipment shock absorber pads, to resist engine high temperature and vehicle vibration.
